Frameset
- Frame
- 6061-T6 aluminum w/ patented Flat Foot Technology®
- Fork
- Hi-ten steel unicrown, straight/tapered leg
Wheels
- Front hub
- Alloy low-flange w/ 6-bolt disc, 36h
- Rear hub
- Alloy low-flange w/ 6-bolt disc, 36h
- Rims
- Anodized alloy 26" × 36h
- Tires
- 26" × 2.35" balloon
Drivetrain
- Shifters
- Shimano Revo 7-speed twist w/ optical gear display
- Front derailleur
- n/a
- Rear derailleur
- Shimano Tourney TY 7-speed
- Crank
- Forged alloy 170 mm, 42t FSA chainring w/ double chainguards
- Bottom bracket
- Hydrive t47 x 155 mm w/ integrated torque sensor
- Cassette
- Shimano 7-speed 14-34t
- Chain
- KMC Z7
- Pedals
- Resin platform w/ non-slip rubber tread
Components
- Saddle
- Ergonomic w/ shock-absorbing elastomers
- Seatpost
- Alloy straight post 27.2 x 350 mm
- Handlebar
- Alloy custom bend 25.9" width/4" rise
- Grips
- Comfort Kraton
- Stem
- Forged alloy 25.4 mm quill, 80 mm extension
- Headset
- 1 1/8" steel threaded/semi-integrated
- Brakeset
- Front/rear: mechanical disc brakes
Accessories
- Battery
- Hydrive 309Wh, rear rack mounted, includes 2 AMP charger
- Motor
- Hydrive rear hub motor, 250w
- Rear carrier
- Rear rack
- Kickstand
- Alloy
- Extras
- Rear rack, front rack compatible, ring lock mounts, internal cable routing, alloy kickstand and stainless steel and anti-rust hardware
Weight
- Weight
- 21.18 kg / 48 lbs
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice. Prices shown are manufacturer's suggested retail prices.
Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
