Specifications

• Frameset

  Frame

  6061-T6 aluminum w/ patented Flat Foot Technology®

  Fork

  Hi-ten steel unicrown, straight/tapered leg

• Wheels

  Front hub

  Alloy low-flange w/ 6-bolt disc, 36h

  Rear hub

  Alloy low-flange w/ 6-bolt disc, 36h

  Rims

  Anodized alloy 26" × 36h

  Tires

  26" × 2.35" balloon

• Drivetrain

  Shifters

  Shimano Revo 7-speed twist w/ optical gear display

  Front derailleur

  n/a

  Rear derailleur

  Shimano Tourney TY 7-speed

  Crank

  Forged alloy 170 mm, 42t FSA chainring w/ double chainguards

  Bottom bracket

  Hydrive t47 x 155 mm w/ integrated torque sensor

  Cassette

  Shimano 7-speed 14-34t

  Chain

  KMC Z7

  Pedals

  Resin platform w/ non-slip rubber tread

• Components

  Saddle

  Ergonomic w/ shock-absorbing elastomers

  Seatpost

  Alloy straight post 27.2 x 350 mm

  Handlebar

  Alloy custom bend 25.9" width/4" rise

  Grips

  Comfort Kraton

  Stem

  Forged alloy 25.4 mm quill, 80 mm extension

  Headset

  1 1/8" steel threaded/semi-integrated

  Brakeset

  Front/rear: mechanical disc brakes

• Accessories

  Battery

  Hydrive 309Wh, rear rack mounted, includes 2 AMP charger

  Motor

  Hydrive rear hub motor, 250w

  Extras

  Rear rack, front rack compatible, ring lock mounts, internal cable routing, alloy kickstand and stainless steel and anti-rust hardware

• Weight

  Weight

  21.18 kg / 48 lbs

  Weight limit

  This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
