TQ HPR50

Small. Light. Quiet. Natural.
HPR50

The heart of TQ-Group’s e-bike transmission is the HPR50— short for harmonic pin ring transmission with 50Nm of torque. What’s a harmonic pin ring transmission? It’s a relatively simple, yet ingenious, drive mechanism that operates similarly to a rotary motor, but more refined. Internally, there are three concentric precision pieces, an elliptical wave generator, inner flex spline, and a circular spline, that come together to propel you forward, while remaining small and lightweight. Compared to classic toothed gears and belt drives, a harmonic pin ring transmission is more compact, more powerful, feels smoother, and is more durable.

Due to their precision, durability and compact design, harmonic pin ring transmissions and specifically TQ harmonic pin ring drives, have been used in the space industry, aviation, the medical industry, and robotics. For all the same reasons they succeed in moon landers and surgery robots, they work great in e-bikes as well.

Light

Tipping the scale at just 1800g, HPR50 is 1100-grams lighter than other high-powered drive systems.

Small

HPR50 tucks neatly behind the front chainring for the clean look of a traditional bike.

Quiet

Foregoing noisy belts and geared teeth, HPR50 measures in as much quieter than other systems.

Learn more

Q-Factor

The small size of HPR50 allows for a minimal 135mm Q-factor (the distance between the outside of one crank and the outside of the opposite crank), providing a comfortable riding position similar to a non-electric bike.

Power density

A balanced 50Nm of torque gives just the right amount of assist that isn’t overwhelming, and doesn’t jerk you around like a full-powered 85-90Nm e-bike.

A better battery

1.

360Wh packed into a lightweight 1835g package.

2.

Fully charge in 2-3 hours.

3.

Daisy chain to charge your booster and battery simultaneously.

4.

Simple removal, just unplug, remove downtube guard and two bolts, and pull out by the handle.

5.

LED charge display illuminates to indicate how much charge your battery has, and let you know when it's full.

Fitting snugly into the existing bottle cage, the Range Extender offers an additional 160Wh of power to increase the range of your ride by 44%

Mounted flush into the toptube, a two-inch display keeps your setup discrete from a side-view, while providing crisp and bright details from the bird’s eye. The bright contrast stays visible in blinding sunlight and offers just enough information to be useful without overwhelming you at a glance. A single button turns the system on and off, and toggles through riding screens.

Control at your fingertips

Fuel EXe handlebar-located remote

Small, stealthy, and easy for everyone but your thumb to miss. The handlebar-located remote, developed specifically for mountain bikes, features two buttons that allow you to toggle through support modes, engage walk assist, and turn off assistance right from the comfort of your grips. Easily unplug the remote when you need to change or replace components.

A bike this advanced and refined deserves an app equally advanced and refined.

Tuned to you

You’re in control with three completely adjustable motor tune settings that can be easily tweaked on the fly.

How far can you go?

See your estimated ride range to plan your route without worries of running out of juice.

Plan your ride

Map out the perfect ride with easy-to-use routes for road and trail alike.

See your stats

Log your rides, keep track of maintenance, and reach your goals with activity tracking.

Plays well with others

Pairs with Strava and Komoot to automatically log your rides across different apps.

Who is TQ?

TQ is a hard hitter in the e-bike world here to refine and redefine the way we ride. Delivering the best of both electric and traditional bikes, TQ’s harmonic pin ring transmission measures in lighter, quieter, and smaller than most other e-bike drive units on the market. Wherever you roam, its assist feels natural and keeps you one with the ride.

Formed in 1994 as "Technologie in Qualität" in the blue lake land of Bavaria, TQ has grown from two founders to a team of over 1,700 employees across 14 locations, with a passion for innovation. Firmly established as one of Germany’s largest and best electronic product specialists in the fields of robotics, embedded systems, automation, medical technology, and aerospace. You’ll find TQ in the moon-rover and robots performing surgery — systems that need to be equally precise and dependable.

TQ embarked on the e-bike journey as long ago as 2008 and has been building the passion, expertise, hardware, industry connections, and plenty of ride time to prove it all out. In short, TQ is your riding buddy who can hold their own with the best while also articulating the subtle nuances of riding to the most minute detail.

Creating a system this new and this different took heaps of collaboration and a whole lot of prototypes. Through the development process, Germany-based TQ and US-based Trek worked exclusively together to fine-tune the HPR50 transmission system for a ride feel that’s unlike anything cycling has ever seen.

Made by bike people passionate about finding a better way to ride, HPR50 provides nearly invisible assist that feels like a hand at your back on steep climbs and stays nimble and natural whether weaving down steep canyon roads or through technical trail terrain.
